Khoom Piav Qhia
SFM65 yog 18- volt 65- watt mono-crystalline lub solar vaj huam sib luag
Qhov loj me: 630 * 660 * 25mm. PRE LWJ DROWES DIODES IN BIDITT BOARCT BOART THIAB IB TUG NTAWM 4mm2 CABLE
High efficial solar hlwb raws li cov thev naus laus zis thev naus laus zis tshiab
Muaj zog txhuas ncej tsim kom tiv thaiv cov daus hnyav thiab cua tshuab hluav taws xob, dhau ib daus load ntawm 5400PA
Pre dr drilled qhov nyob rau sab nraum qab ntawm lub vaj huam sib luag rau nrawm mounting thiab ruaj khov
Chaw ua uas tsis tau haus
|
Cov yam ntxwv hluav taws xob (STC *) |
||||||||
|
Qauv NO. (SFP) |
Lub zog siab tshaj ntawm STC (PMAX) |
VMP (v) |
Imp (a) |
VOC (v) |
ISC (A) |
Qho loj dav |
Hnub ci cell loj (hli) |
Hnub ci Hlawv Kis Qauv Txawv |
|
Sf 18-5 m |
5WP |
9V |
0.58A |
10.8 |
0.64A |
150*350*17 |
156*10.4 |
2*9 |
|
Sf 36-10 m |
10WP |
18V |
0.56A |
21.6V |
0.61A |
260*350*17 |
156*10.4 |
2*18 |
|
Sf 36-20 m |
20WP |
18V |
1.11A |
21.6V |
1.22A |
480*350*17/25 |
156*22.2 |
2*18 |
|
Sf 36-25 m |
25WP |
18V |
1.39A |
21.6V |
1.53A |
540*350*17/25 |
156*26 |
2*18 |
|
Sf 36-30 m |
30WP |
18V |
1.65A |
22.2V |
1.8A |
635*350*17/25 |
156*31.2 |
2*18 |
|
340*660*17/25 |
156*31.2 |
4*9 |
||||||
|
440*510*17/25 |
156*31.2 |
3*12 |
||||||
|
Sf 36-40 m |
40wP |
18V |
2.23A |
21.6V |
2.45A |
410*660*25 |
156*39 |
4*9 |
|
535*510*25 |
156*39 |
3*12 |
||||||
|
Sf 36-50 m |
50WP |
18V |
2.78A |
21.6V |
3.06A |
540*660*25 |
156*52 |
4*9 |
|
630*540*25 |
125*62.5 |
4*9 |
||||||
|
Sf 36-60 m |
60WP |
18V |
3.34A |
21.6V |
3.67A |
540*660*25 |
156*52 |
4*9 |
|
Sf 36-65 m |
65WP |
18V |
3.62A |
21.6V |
3.97A |
630*660*25 |
156*62.4 |
4*9 |
|
Sf 36-70 m |
70WP |
18V |
3.9A |
21.6V |
4.28A |
630*660*25 |
156*62.4 |
4*9 |
|
Sf 36-75 m |
75WP |
18.2V |
4.12A |
21.84V |
4.53A |
670*660*25 |
156*67 |
4*9 |
|
Sf 36-80 m |
80WP |
18.6V |
4.3A |
22.4V |
4.69A |
765*660*25 |
156*78 |
4*9 |
|
Sf 36-85 m |
85WP |
18V |
4.73A |
21.61V |
5.19A |
765*660*25 |
156*78 |
4*9 |
|
Sf 36-90 m |
90WP |
18V |
5A |
21.6V |
5.5A |
765*660*25 |
156*78 |
4*9 |
|
Sf 36-95 m |
95wP |
18V |
5.27A |
21.6V |
5.51A |
910*660*25/30 |
156*93.6 |
4*9 |
|
Sf 36-100 m |
100WP |
18.12V |
5.52A |
21.7V |
6.07A |
910*660*25/30 |
156*93.6 |
4*9 |
|
1200*540*25/30 |
125*125 |
4*9 |
||||||
|
Sf 36-110 m |
110Wp |
18.2V |
6.05A |
21.84V |
6.65A |
1010*660*25/30 |
156*104 |
4*9 |
|
1200*540*25/30 |
125*125 |
4*9 |
||||||
|
Sf 36-120 m |
120WP |
18V |
6.67A |
21.6V |
7.33A |
1010*660*25/30 |
156*104 |
4*9 |
|
1200*540*25/30 |
125*125 |
4*9 |
||||||
|
Noct |
45 ± 2 degree |
|||||||
|
Pmax kub coefficient |
{{0 {}}. 42% \/ Qib |
|||||||
|
Voc Kub Coefficient |
{{0 {}}. 32% \/ degree |
|||||||
|
ISC kub coefficient |
0. 06% \/ Qib |
|||||||
|
Cia kub |
Los ntawm -40 rau +60 degree |
|||||||
|
Kev khiav hauj lwm kub |
Los ntawm -40 rau +85 degree |
|||||||
|
Ncej Khoom |
Anodized aluminium alloy |
|||||||
|
Hnub ci hlwb |
Mono-crystalline silicon |
|||||||
|
Pem Hauv Ntej (Khoom \/ Thickness) |
3.2mm ({{0. 13in) qhov txias txias iav |
|||||||
|
Encapsulate |
Ethylene vinyl acetate |
|||||||
|
Hnub ci cables |
UV REIGTANT SDAR CABLE (YOOJ YIM) |
|||||||
|
Tus sib txuas |
MC4 (yeem) |
|||||||
Lub thawv
Yam zoo
El kuaj cov hnub ci; tsis muaj kub-chaw ua cua sov tau txais
Kev Tso Cai UPS 1703 Photos-VoltaIC Modules thiab Panels
High efficiency solar hlwb, Aluminium ncej Solar vaj huam sib luag
- Ruaj khov
Muaj peev xwm ntawm nrog cov cua hlob heev, txog 2400 pa, thiab daus thauj ntawm 5400 pa
Corrosion-resistant txhuas ncej rau ncua sab nraum zoov siv
Anti-reflective, siab pob tshab, tsis muaj hlau loj heev iav nrog ua kom muaj zog ruaj khov thiab cuam tshuam tsis kam
Ip65 Rated Lomitt Box muab kev tiv thaiv tiav rau ib puag ncig cov khoom siv thiab cov dav hlau dej qis
- Muaj peev xwm
Tuaj yeem siv rau ntau daim ntawv thov sib txawv, txawm tias ua haujlwm tau, chaw ua haujlwm, pw hav zoov, tsheb, tsheb board teeb pom kev zoo, kev ruaj ntseg tshuab
Txog Peb
Qinhuangdao Sufu Electronic Co., Ltd yog lub hnub ci niaj hnub, hnub ci system cov kev daws teeb meem thiab cov chaw xa khoom. Peb cov khoom lag luam hnub ci muaj ntau ntawm cov hnub ci ntsa iab rau cov teeb meem hnub ci, hnub ci hluav taws xob teeb pom kev zoo, lub hnub ci (BACK) tsim qauv thiab kev tsim kho.
Hauing tshaj kev cob qhia ntawm 30, 000 ㎡, thawj ntu ntu yog 20 lub sijhawm ua ntej peb txhua xyoo ntawm 20mW rau ob qho tib si mono thiab poly solar panels.
Sufu tau muab cov khoom siv thoob ntiaj teb txhim khu kev qha thiab cov khoom lag luam tshiab uas muaj ntawv pov thawj thoob ntiaj teb nrog TUV, CE, IEC thiab ISO9001 thiab lwm yam.
Cov khoom siv rau ntau cov neeg siv khoom suav nrog Australia, Is Nrias teb, Neeg Kauslim, South America, Nruab Nrab Asia, Africa thiab lwm lub tebchaws.
Daim ntawv muaj cai
Vim li cas thiaj xaiv peb?
1. Peb muaj peb tus kheej lub Hoobkas nrog kev tshaj lij rau cov vaj huam sib luag solar thiab system tshaj 10 xyoo.
2. Peb muaj pab pawg R & D.
3. Muab kev pabcuam OEM rau koj daim ntawv xaj.
4. Teb hauv 12 teev.
5. Muab tus nqi sib tw, kev pabcuam tom qab muag khoom zoo.
Cov FAQ
Q: Ua rau cov lus qhia tawm?
Cov vaj huam sib luag hnub ci kev ntsuas tau suav hauv lub hnub ci ncaj qha. Cov xwm txheej xws li lub hnub ci tsis ncaj ncees, overcast thiab ib nrab ntxoov ntxoo yuav txo qis cov zis.
Q: Dab tsi yog qhov sib txawv ntawm mono vs. poly solar cell?
Mono yog thawj ntau yam ntawm lub hnub ci ci thiab yog laus dua poly. Piv rau mono hnub ci panels, poly tsis tshua kim thiab yooj yim dua los tsim.
Q: Puas yog cov pov thawj huab cua huab cua?
Yuav luag txhua lub hnub ci ntsa iab yog tsim rau sab nraum zoov teeb tsa, raws li qhov no yog qhov uas lawv yuav tau txais qhov zoo tshaj plaws, feem ntau raug rau kev tshav ntuj. Nco ntsoov tias ib yam dab tsi tsawg dua li uas yuav ua rau cov vaj huam sib luag los tsim tsawg dua nws lub zog puv ntoob.
Q: Kuv puas yuav tsum tuav cov vaj huam sib luag ci ntsa iab?
Kev tshuaj xyuas ib ntus kom tshem tawm cov av, khib nyiab thiab tshuaj xyuas cov kev sib txuas hluav taws xob yog txhua yam uas xav tau. Ua kom lub vaj huam sib luag ntshiab ntawm daus thiab khib nyiab yuav tso cai rau cov txiaj ntsig zoo dua.
Q: Ntev npaum li cas hnub ci ntsa iab kawg?
Kev ua tau los ntawm lub solar vaj huam sib luag yuav txawv, tab sis feem ntau tau lees tias muaj zog hluav taws xob kev cia siab yog nyob nruab nrab ntawm 3 thiab 25 xyoos. Qhov no lav tau lub neej kev cia siab qhov kev ntsuam xyuas feem ntau yog 80% ntawm kev tshaj tawm kev tshaj tawm ntawm lub ntiaj teb vaj huam sib luag.
