Khoom Piav Qhia
1. HOM PHIAJ
2. SMD Diode HY SDA2040
3. PPO Khoom Siv Lub thawv
4. 4sqmm 300mm (Txuj Ci)
5. Potting nplaum hom
6. 10Yog pib lub Hoobkas ua rog, 25 xyoo kev pabcuam lub neej
7. TUV Daim Ntawv Pov Thawj, IP67
8. Bipv, Ob Chav iav Solar vaj huam sib luag siv.
Chaw ua uas tsis tau haus
| Kev qhia tshwj xeeb | No. ntawm Terminal | No. ntawm Diode | Diode hom | Kev ncua deb ntawm cov terminals | Txoj kev ib ncig ib qho chaw |
| PV-sc1701 | 6 | 3 | SPA2040 | 20mm |  |
|
Lub hom phiaj |
En 50548: 2011+ A1 |
|
Cov Ntsuas Hluav Taws Xob |
1500VDC |
|
Max.Working Voltage |
100VDC |
|
Rated tam sim no |
12A |
|
Degion degree |
0 |
|
Kev Tiv Thaiv Chav Kawm |
Chav Kawm ⅱ |
|
Kev tiv thaiv degree |
Ms67 |
|
Nplaim taws |
Ul {{0}} v0 |
|
Qhov ntsuas kub ntau |
{{0 {}} degree ~ +85 degree |
|
Txuas Txuas Cable |
1×4m㎡ |
|
Cov qauv dej tsis muaj dej |
Potting Sealing |
|
Dav ntawm tooj liab ribbon |
Txog 8 hli |
|
Txoj kev sib txuas |
Soldering |
|
Rwb thaiv tsev ntaub |
Nyiaj tso |
|
Cov Khoom Sib Hu |
Tooj liab alloy, npib tsib xee plated |
|
Zuag Tawm Ib Zos |
52 x 52x15 mm x 3 |
|
Tsevneeg Kho |
Silica Gel |
|
Thaj chaw sib cog lus |
1700m㎡ X 3 |
|
Tus txuas |
PV-Sc01 |
Daim duab
Yam zoo
1701 hlws ris lub tsev nyob rau hluav taws xob sib cuam tshuam hauv txoj hlua ntawm cov qauv. Nws tseem yog lub tsev hla kev hla kev (cov) kev sib cais los ntawm cov kab mob hotspot Qhov no yuav tag nrho txhim kho lub neej ntawm bypass diode thiab ntxiv lub hnub ci module.
Daim ntawv muaj cai
Cov FAQ
Q: Koj cov khoom tseem ceeb yog dab tsi?
Koj tuaj yeem tau txais ib qho khoom ntawm PV system los ntawm peb.
Peb yog cov chaw tsim khoom ntawm cov vaj huam sib luag lub hnub ci, Hnub ci sib tshuam lub thawv, hnub ci txuas thiab hluav taws xob system.
Q: Ntev npaum li cas lub sij hawm txiav txim ntawm kev txiav txim?
Txoj kev tsim qauv nrawm nrawm yog sai: peb tuaj yeem muab cov txheej txheem tsim qauv tag nrho hauv 3 hnub ua haujlwm tom qab lees paub tus neeg yuav tsum tau ua.
Cov khoom lag luam ceev ceev: Peb tuaj yeem xa cov khoom lag luam tsis pub dhau 20 hnub ua haujlwm (tsis suav nrog lub sijhawm thauj) tom qab tus neeg tau lees paub txoj kev npaj thiab peb tau txais cov nyiaj ua ntej.
Q: Koj puas tuaj yeem muab daws?
Yog lawm, sib txuas lus tag nrho nrog cov neeg siv khoom, nkag siab cov neeg siv khoom rau cov neeg siv khoom rau cov neeg yuav khoom, muab cov duab kos rau cov neeg siv khoom kom paub meej.
